Industrial 4G Wifi Router Module
4g-wifi-router-module-02

Sailsky High Quality Industrial 4G Wifi Router Module for Video Transmission and Ip Camera

Model: 4G Module 4G Router

Key Features:

  • LTE Cat 4 wireless module designed for M2M and loT applications
    Multi-network standard coverage.
  • Support FOTA remote upgrade and eCall* function.
  • MIMO technology meets data communication and connection
    reliability requirements for wireless communication systems
    Su per cost-effective.

Share it:

Share it:

Interested?

Welcome to Contact Us for a Quotation!

Ship within 7-10 Working Days for Stocking Products,Customized product should be negotiated

Specifications

Product application scenario Outdoor/remote area monitoring
Product Model 4G Module
Product Name Sailsky 4G Master Control Board Video Transmission Via 4G signals/LTE Modules 4G with SIM Card
Product Keywords WiFi Sim Card 4G
Master control MTK7628KN inclusion 8MB DDR1
Flash 2MB
Interface
  • 1 *10/100 Mbps WAN Port
  • 1* 10/100 Mbps LAN Port
Button Reset (long press 3-5 seconds to restore default factory configuration) / WPS (long press 1-2 seconds)
Power supply DC12V /1A
LED PWR, WiFi, 4G blue indicator
Size 38*50(mm)
Antenna
  • 2.4G(802.11n) :2T2R
  • 4G:2T2R
Working Channel 1-13
Antenna gain 5dBi
Frequency range 2.4~2.4835GHz
Transmission speed
  • 11b: 1 /2 /5.5 /11Mbps
  • 11g: 6 /9 /12 /18 /24 /36 /48 /54Mbps
  • 11n: Up to 300 Mbps system time settings system log
Spread spectrum technology DSSS (Direct Sequence Spread Spectrum)
Data encryption WPA-PSK/WPA2-PSK,WPA/WPA2
Data modulation mode
  • 11b: CCK. QPSK, BPSK
  • 11g: OFDM
  • 11n: QPSK, BPSK, 16-QAM, 64-QAM
Media access protocol CSMA/CA with ACK
WiFi transmission power
  • 11b: 18dBm@1~11Mbps
  • 11g: 16dBm@6~54Mbps
  • 11n: 15dBm@MCS0-7
Accept sensitivity
  • 11b: <-84dBm@11Mbps ,
  • 11g: <-69dBm@54Mbps ,
  • 11n: HT20 <,-67dBm,
  • HT40<-64dBm
Network standard / GNSS  LTE CAT4
LTE-FDD (supports diversity reception) B1/B3/B5/B8/(B28)
LTE-TDD (supports diversity reception) B38/B39/B40/B41
WCDMA (supports diversity reception) B1/B8

Download

Sailsky High Quality Industrial 4G Wifi Router Module for Video Transmission and Ip Camera

If you are looking for an extremely reliable 4G Wifi Router Module for video transmission and IP camera with perfection then you should consider buying Sailsky High-Quality Industrial 4G Wifi Router Module for Video Transmission and IP Camera.

This device is especially comes into being for M2M and loT applications. This is so far one of the best cost-effective solutions ever because extremely advance MIMO technology has been install into it. It is responsible for reliable and smooth connections.

It is perfect for the outdoor areas too. There is no need to be a worry at all about seasonal changes because it can withstand all.  Whether the temperature is humid, colder, or heater it will not be corrupted and damaged at all. Its physical interface contains 1 *10/100 Mbps WAN Port, 1* 10/100 Mbps LAN Port. The external design is not messy at all, it contains only the Reset button in order to use it you need to long-press 3-5 seconds to restore default factory configuration / WPS long press 1-2 seconds.

It contains a 4G blue LED indicators too that give alerts whether it’s working or not.

This device is perfect for IP cameras; we assure you that its feature will never disappoint you.

Also SHOP: Sailsky XM250 300Mbps Industrial Router with 4G Sim Card Sot
